Mainly used in the carbon industry, light materials, chemical industry, and particle size classification of fine particle materials.
product details
Industry solutions:lTightly sealed against dust
lThe screen can achieve multi-layer and multiple material particle size classification, and has a compact structure.
lThe exciting force of the vibrator is easy to adjust.
lThe track of the screen realizes a long ellipse screening, which is convenient for material transportation and grading, and the screening efficiency is high.
Technical Parameters
Screen model | Layer No. | Screening surface size(mm) | Screen area(m²) | Opening size(mm) | Power(Kw) |
PZKT1248 | 1 | 1250X4800 | 5.76 | 1-20 | 5.5X2 |
PZKT1848 | 1 | 1850X4800 | 8.64 | 1-20 | 7.5X2 |
2PZK1536 | 2 | 1550X3600 | 10.8X2 | 1-20 | 5.5X2 |
2PZKT1248 | 2 | 1250X4800 | 5.76X2 | 1-20 | 7.5X2 |
2PZKT1648 | 2 | 1650X4800 | 7.68X2 | 1-20 | 7.5X2 |
2PZKT1848 | 2 | 1850X4800 | 8.64X2 | 1-20 | 7.5X2 |
3PZK1236 | 3 | 1250X3600 | 4.32X3 | 1-20 | 7.5X2 |
3PZK1448 | 3 | 1450X4800 | 6.72X3 | 1-20 | 7.5X2 |
3PZK1536 | 3 | 1550X3600 | 5.4X3 | 1-20 | 7.5X2 |
3PZKF2148 | 3 | 2150X4800 | 10.08X3 | 1-20 | 15X2 |
3PZKT1648 | 3 | 1650X4800 | 7.68X3 | 1-20 | 11X2 |
3PZK1848 | 3 | 1850X4800 | 8.64X3 | 1-20 | 11X2 |
4PZK1030 | 4 | 1050X3000 | 3X4 | 1-20 | 11X2 |
4PZK1236 | 4 | 1250X3600 | 4.32X4 | 1-20 | 7.5X2 |
4PZKT2148 | 4 | 2150X4800 | 10.08X4 | 1-20 | 30X2 |
