  • TAB(TKB)series amplitude descending elliptic vibrating screen

TAB(TKB)series amplitude descending elliptic vibrating screen

Share:

TAB (TKB) Series Amplitude Descending Elliptic Vibrating Screen is applicable to classification of coal which feed size≤400mm.

product details

Industry solutions:

TAB(TKB)series amplitude descending elliptic vibrating screen

TAB (TKB) Series Amplitude Descending Elliptic Vibrating Screen is applicable to classification of coal which feed size≤400mm. Compared with traditional circular vibrating screen with the same specification, this screen has the advantages of large production capacity and high screening efficiency.

Notice to Order

1, Capacity is calculated based on bulk density of 1 t/m3. The capacity in the table is only for reference.

2, Form of screen cloth : ①Punched Steel Plate ②Polyurethane squre or long hole ③Woven wire ④ grizzly. The top mesh shall be in accordance with ①, the bottom shall be③, in case not specially required.

3, When ordering, besides model and quantity, please also indicate opening size ,shape and mesh material.

4, The motor may be installed either on the left or on the right. If there is no special requirement, the motor shall be installed on the left. If user has requirement, please specify in the contract.

5, In case the client has special requirements,we can do special design and manufacture for our customers

Technical Parameters

Deck numberModel Deck area (m2)Opening size (mm)Capacity(t/h) Motor Power (KW)
Single-deckTAB307221.65-100240-13002×30
TAB367225.925-100280-15002×37
TAB388231.165-100340-18002×45
TAB428234.445-100370-20002×55
Double-deck2TAB30722x21.6upper: 25-100 lower: 5-50650-13002×30
2TAB36722x25.92upper: 25-100 lower: 5-50750-15002×37
2TAB38822x31.16upper: 25-100 lower: 5-50900-18002×45
2TAB42822x34.44upper: 25-100 lower: 5-501000-20002×55
2TKB501132x56.5upper: 25-100 lower: 5-501200-28004×45


The circular vibrating screen is a new screening equipment, the vibrational trajectory is an ellipse, is designed specifically for material stone screening in quarry, but also used for coal preparation, mineral processing, building materials, electricity and chemical departments for product classification.

Advantages and Characteristics

Novelstructure, advanced technical parameters, large capacity, high screening efficiency

Adoptcylinder type of eccentric shaft vibration exciter and an eccentric block for amplitude adjustment, easy to use and maintain

Adopt tire coupling, soft connection makes operationsmooth

Adoptspring steel woven screen or punched screen plate, long useful life and no plugging

Long life, quiet, smooth resonanceregion
